At present, disposable paper cups or plastic cups are frequently used in various occasions. However, due to their thin body and no handle, they usually need to be equipped with cup holders. At present, the cup holders are generally made of plastic or other hard materials. Although the cup holders made of this material can be reused, due to their relatively large volume, It is generally equipped with cup handles, which are not easy to carry in travel, picnic and other outdoor activities. Due to the existence of cup handles, they can not be set one by one to reduce the occupied space, and they are not easy to clean outside, so it is very inconvenient to use.

為了克服現有技術的不足，本實用新型的目的在于提供一種紙質折疊杯托，通過把托身與托底分別設計成獨立的環狀結構，在托身、托底和連接條上均壓有折痕線，在使用前處于折疊狀態，有效節省占用空間，方便攜帶。

In order to overcome the shortcomings of the prior art, the purpose of the utility model is to provide a paper folding cup holder. By designing the holder body and the holder bottom into an independent ring structure respectively, a crease line is pressed on the holder body, the holder bottom and the connecting strip, which is in a folded state before use, effectively saving occupied space and convenient to carry.

目的采用以下技術方案實現：

The purpose is realized by the following technical scheme:

提供一種紙質折疊杯托，包括用于固定杯身的托身，用于支撐杯身的托底，托身與托底分別為中空的圓環結構，托底直徑小于托身直徑，托身與托底相對的兩端分別軸向壓有托身折痕線和托底折痕線；托身與托底之間設有連接條，連接條一端連接托身的環壁，另一端連接托底的環壁，連接條上橫向壓有若干條連接折痕線。

The utility model provides a paper folding cup holder, which comprises a holder body for fixing the cup body and a holder bottom for supporting the cup body. The holder body and the holder bottom are hollow ring structures respectively, the diameter of the holder bottom is less than the diameter of the holder body, and the two opposite ends of the holder body and the holder bottom are axially pressed with the holder body crease line and the holder bottom crease line respectively; A connecting strip is arranged between the supporting body and the supporting bottom, one end of the connecting strip is connected with the ring wall of the supporting body, the other end is connected with the ring wall of the supporting bottom, and several connecting crease lines are pressed laterally on the connecting strip.

托身為瓦楞紙板，包括表層、內層以及設置在表層與內層之間的瓦楞紙層，瓦楞紙層包括空心正八邊形瓦楞紙芯和空心梯形瓦楞紙芯，空心正八邊形瓦楞紙芯橫向平均排列且左右對稱的兩個平面分別與一一對應粘貼，空心正八邊形瓦楞紙芯上下對稱的兩個平面分別與空心體形瓦楞紙芯的短邊對應粘貼，空心梯形瓦楞紙芯的長邊分別粘貼與表層與內層上。

The supporting body is corrugated board, including the surface layer, the inner layer and the corrugated paper layer arranged between the surface layer and the inner layer. The corrugated paper layer includes hollow regular octagonal corrugated paper core and hollow trapezoidal corrugated paper core. The hollow regular octagonal corrugated paper core is arranged horizontally and evenly, and the two planes symmetrical on the left and right are pasted one by one, The upper and lower symmetrical planes of the hollow regular octagonal corrugated paper core are respectively pasted with the short side of the hollow body corrugated paper core, and the long side of the hollow trapezoidal corrugated paper core is pasted with the surface layer and the inner layer respectively.

空心正八邊形瓦楞紙芯邊長與空心體形瓦楞紙芯的短邊長度相等；空心正八邊形瓦楞紙芯對稱兩個頂角之間的長度與所述空心體形瓦楞紙芯的長邊長度相等。內層涂覆有防水膜。

The side length of hollow regular octagonal corrugated paper core is equal to the short side length of hollow body corrugated paper core; The length between the two symmetrical top corners of the hollow regular octagonal corrugated paper core is equal to the length of the long side of the hollow body corrugated paper core. The inner layer is coated with waterproof membrane.
